VSTI-R-Blanking plug for ports Male BSPP thread
L SERIES
| A THREAD |
L LENGTH |
I |
ØD |
S1 A/F Hex |
Part Number |
Working pressure in Bar for CS |
Working pressure in Bar for SS |
| G1/8"-28-BSPP-A |
12.30 |
8.00 |
14.00 |
5.00 |
VSTIR1-8"BSPED |
400 |
400 |
| G1/4"-19-BSPP-A |
17.30 |
12.00 |
19.00 |
6.00 |
VSTIR1-4"BSPED |
400 |
400 |
| G3/8"-19-BSPP-A |
17.30 |
12.00 |
22.00 |
8.00 |
VSTIR3-8"BSPED |
400 |
400 |
| G1/2"-14-BSPP-A |
19.30 |
14.00 |
27.00 |
10.00 |
VSTIR1-2"BSPED |
400 |
400 |
| G3/4"-14-BSPP-A |
21.30 |
16.00 |
32.00 |
12.00 |
VSTIR3-4"BSPED |
400 |
400 |
| G1"-11-BSPP-A |
22.80 |
16.00 |
40.00 |
17.00 |
VSTIR1"BSPED |
400 |
400 |
| G1-1/4"-11-BSPP-A |
22.80 |
16.00 |
50.00 |
22.00 |
VSTIR1-1-4"BSPED |
315 |
315 |
| G1-1/2"-11-BSPP-A |
22.80 |
16.00 |
55.00 |
24.00 |
VSTIR1-1-2"BSPED |
315 |
315 |
S SERIES
| A THREAD |
L LENGTH |
I |
ØD |
S1 A/F Hex |
Part Number |
Working pressure in Bar for CS |
Working pressure in Bar for SS |
| G1/8"-28-BSPP-A |
12.30 |
8.00 |
14.00 |
5.00 |
VSTIR1-8"BSPED |
400 |
400 |
| G1/4"-19-BSPP-A |
17.30 |
12.00 |
19.00 |
6.00 |
VSTIR1-4"BSPED |
400 |
400 |
| G3/8"-19-BSPP-A |
17.30 |
12.00 |
22.00 |
8.00 |
VSTIR3-8"BSPED |
400 |
400 |
| G1/2"-14-BSPP-A |
19.30 |
14.00 |
27.00 |
10.00 |
VSTIR1-2"BSPED |
400 |
400 |
| G3/4"-14-BSPP-A |
21.30 |
16.00 |
32.00 |
12.00 |
VSTIR3-4"BSPED |
400 |
400 |
| G1"-11-BSPP-A |
22.80 |
16.00 |
40.00 |
17.00 |
VSTIR1"BSPED |
400 |
400 |
| G1-1/4"-11-BSPP-A |
22.80 |
16.00 |
50.00 |
22.00 |
VSTIR1-1-4"BSPED |
315 |
315 |
| G1-1/2"-11-BSPP-A |
22.80 |
16.00 |
55.00 |
24.00 |
VSTIR1-1-2"BSPED |
315 |
315 |
