ROV-Blanking plug for tube ends

ROV-Blanking plug for tube ends

L SERIES

Tube O.D. A THREAD S1 Hex S2 Hex L Length ØP Body Part Number Assembly Part Number Working pressure in Bar for CS Working pressure in Bar for SS
6 M12X1.5-6g 12.00 14.00 14.00 6.00 XROV06L ROV06L 315 330
8 M14X1.5-6g 14.00 17.00 15.00 8.00 XROV08L ROV08L 315 330
10 M16X1.5-6g 17.00 19.00 16.00 10.00 XROV10L ROV10L 315 330
12 M18X1.5-6g 19.00 22.00 17.00 12.00 XROV12L ROV12L 315 330
15 M22X1.5-6g 24.00 27.00 18.00 15.00 XROV15L ROV15L 315 330
18 M26X1.5-6g 27.00 32.00 19.00 18.00 XROV18L ROV18L 315 330
22 M30X2.0-6g 32.00 36.00 21.00 22.00 XROV22L ROV22L 160 160
28 M36X2.0-6g 41.00 41.00 22.00 28.00 XROV28L ROV28L 160 160
35 M45X2.0-6g 46.00 50.00 25.00 35.00 XROV35L ROV35L 160 160
42 M52X2.0-6g 55.00 60.00 27.00 42.00 XROV42L ROV42L 160 160

S SERIES

Tube O.D. A THREAD S1 Hex S2 Hex L Length ØP Body Part Number Assembly Part Number Working pressure in Bar for CS Working pressure in Bar for SS
6 M14X1.5-6g 14.00 17.00 18.00 6.00 XROV06S ROV06S 630 630
8 M16X1.5-6g 17.00 19.00 20.00 8.00 XROV08S ROV08S 630 630
10 M18X1.5-6g 19.00 22.00 20.00 10.00 XROV10S ROV10S 630 630
12 M20X1.5-6g 22.00 24.00 22.00 12.00 XROV12S ROV12S 630 630
16 M24X1.5-6g 27.00 30.00 24.00 16.00 XROV16S ROV16S 400 410
20 M30X2.0-6g 32.00 36.00 28.00 20.00 XROV20S ROV20S 400 410
25 M36X2.0-6g 41.00 46.00 32.00 25.00 XROV25S ROV25S 400 410
30 M42X2.0-6g 46.00 50.00 34.00 30.00 XROV30S ROV30S 400 410
38 M52X2.0-6g 55.00 60.00 39.00 38.00 XROV38S ROV38S 315 320
