EVGE-M-Stand Pipe Adaptor

EVGE-M-Stand Pipe Adaptor

L SERIES

Tube O.D. A THREAD B THREAD S1 Hex S2 Hex L ØD DRILL ØD1 Body Part Number Assembly Part Number Working pressure in Bar for CS Working pressure in Bar for SS
6 M10X1.5-6g M12X1.5-6H 14.00 14.00 32.50 4.00 6.00 XSP06LM EVGE06LM 315 315
8 M12X1.5-6g M14X1.5-6H 17.00 17.00 38.50 6.00 8.00 XSP08LM EVGE08LM 315 315
10 M14X1.5-6g M16X1.5-6H 19.00 19.00 39.50 7.00 10.00 XSP10LM EVGE10LM 315 315
12 M16X1.5-6g M18X1.5-6H 22.00 22.00 41.50 9.00 12.00 XSP12LM EVGE12LM 315 315
15 M18X1.5-6g M22X1.5-6H 24.00 27.00 43.50 11.00 15.00 XSP15LM EVGE15LM 315 315
18 M22X1.5-6g M26X1.5-6H 27.00 32.00 45.50 18.00 18.00 XSP18LM EVGE18LM 315 315
22 M26X1.5-6g M30X2.0-6H 32.00 36.00 48.50 18.00 22.00 XSP22LM EVGE22LM 160 160
28 M33X2.0-6g M36X2.0-6H 41.00 41.00 53.00 23.00 28.00 XSP28LM EVGE28LM 160 160
35 M42X2.0-6g M45X2.0-6H 50.00 50.00 62.50 30.00 35.00 XSP35LM EVGE35LM 160 160
42 M48X2.0-6g M52X2.0-6H 55.00 60.00 68.20 36.00 42.00 XSP42LM EVGE42LM 160 160

S SERIES

Tube O.D. A THREAD B THREAD S1 Hex S2 Hex L ØD DRILL ØD1 Body Part Number Assembly Part Number Working pressure in Bar for CS Working pressure in Bar for SS
6 M12X1.5-6g M14X1.5-6H 17.00 17.00 39.00 4.00 6.00 XSP06SM EVGE06SM 630 630
8 M14X1.5-6g M16X1.5-6H 19.00 19.00 41.50 5.00 8.00 XSP08SM EVGE08SM 630 630
10 M16X1.5-6g M18X1.5-6H 22.00 22.00 44.00 7.00 10.00 XSP10SM EVGE10SM 630 630
12 M18X1.5-6g M20X1.5-6H 24.00 24.00 46.00 8.00 12.00 XSP12SM EVGE12SM 630 630
14 M20X1.5-6g M22X1.5-6H 27.00 27.00 50.00 10.00 14.00 XSP14SM EVGE14SM 630 630
16 M22X1.5-6g M24X1.5-6H 27.00 30.00 51.00 12.00 16.00 XSP16SM EVGE16SM 400 400
20 M27X2.0-6g M30X2.0-6H 32.00 36.00 59.00 16.00 20.00 XSP20SM EVGE20SM 400 400
25 M33X2.0-6g M36X2.0-6H 41.00 46.00 66.00 20.00 25.00 XSP25SM EVGE25SM 400 400
30 M42X2.0-6g M42X2.0-6H 50.00 50.00 71.00 25.00 30.00 XSP30SM EVGE30SM 250 250
38 M48X2.0-6g M52X2.0-6H 55.00 60.00 82.00 32.00 38.00 XSP38SM EVGE38SM 250 250
