EL-Swivel nut run tee 24° cone end

EL-Swivel nut run tee 24° cone end

L SERIES

Tube O.D. A THREAD B THREAD S1 Hex S2 Hex S3 Hex L1 L2 L3 L4 ØD ØD1 ØP Body Part Number Assembly Part Number Working pressure in Bar for CS Working pressure in Bar for SS
8 M14X1.5-6g M14X1.5-6H 14.00 17.00 17.00 21.00 27.00 29.00 6.00 4.00 8.00 XEL08L EL08L 500 330
10 M16X1.5-6g M16X1.5-6H 14.00 19.00 19.00 22.00 28.50 30.00 8.00 6.00 10.00 XEL10L EL10L 500 330
12 M18X1.5-6g M18X1.5-6H 17.00 22.00 22.00 24.00 29.00 32.00 10.00 8.00 12.00 XEL12L EL12L 400 330
15 M22X1.5-6g M22X1.5-6H 19.00 27.00 27.00 28.00 32.00 36.00 12.00 10.00 15.00 XEL15L EL15L 400 330
18 M26X1.5-6g M26X1.5-6H 24.00 32.00 32.00 31.00 35.00 40.00 15.00 14.00 18.00 XEL18L EL18L 400 330
22 M30X2.0-6g M30X2.0-6H 27.00 36.00 36.00 35.00 38.00 44.00 19.00 18.00 22.00 XEL22L EL22L 250 160
28 M36X2.0-6g M36X2.0-6H 36.00 41.00 41.00 38.00 41.50 47.00 24.00 22.00 28.00 XEL28L EL28L 250 160
35 M45X2.0-6g M45X2.0-6H 41.00 50.00 50.00 45.00 51.00 56.00 30.00 28.00 35.00 XEL35L EL35L 250 160
42 M52X2.0-6g M52X2.0-6H 50.00 60.00 60.00 51.00 56.00 63.00 36.00 34.00 42.00 XEL42L EL42L 250 160

S SERIES

Tube O.D. A THREAD B THREAD S1 Hex S2 Hex S3 Hex L1 L2 L3 L4 ØD ØD1 ØP Body Part Number Assembly Part Number Working pressure in Bar for CS Working pressure in Bar for SS
8 M16X1.5-6g M16X1.5-6H 14.00 19.00 19.00 24.00 27.00 32.00 5.0 4.00 8.00 XEL08S EL08S 800 630
10 M18X1.5-6g M18X1.5-6H 17.00 22.00 22.00 25.00 29.50 34.00 7.0 6.00 10.00 XEL10S EL10S 800 630
12 M20X1.5-6g M20X1.5-6H 17.00 24.00 24.00 29.00 30.50 38.00 8.0 8.00 12.00 XEL12S EL12S 630 630
16 M24X1.5-6g M24X1.5-6H 24.00 30.00 30.00 33.00 36.00 43.00 12.0 11.00 16.00 XEL16S EL16S 630 410
20 M30X2.0-6g M30X2.0-6H 27.00 36.00 36.00 37.00 44.00 48.00 16.0 14.00 20.00 XEL20S EL20S 420 410
25 M36X2.0-6g M36X2.0-6H 36.00 46.00 46.00 42.00 49.50 54.00 20.0 18.00 25.00 XEL25S EL25S 420 410
30 M42X2.0-6g M42X2.0-6H 41.00 50.00 50.00 49.00 55.0 62.00 25.0 23.00 30.00 XEL30S EL30S 420 410
38 M52X2.0-6g M52X2.0-6H 50.00 60.00 60.00 57.00 63.0 72.00 32.0 30.00 38.00 XEL38S EL38S 420 320
