O-Seal NPT Male Connector
CONNECTS FRACTIONAL TUBE TO FEMALE NPT THREAD
| Part No. |
Tube O.D. (in) |
Tube O.D. (mm) |
T (NPT) |
D (mm) |
O Min (in) |
O Min (mm) |
A (in) |
A (mm) |
B (mm) |
l (mm) |
l1 (mm) |
L (mm) |
h (mm) |
H (mm) |
O-Ring Size |
| AMC 2-2NO |
1/8 |
3.17 |
1/8 |
2.28 |
3/4 |
19.05 |
7/16 |
11.11 |
12.70 |
15.24 |
26.16 |
7.11 |
32.76 |
-013 |
| AMC 4-2NO |
1/4 |
6.35 |
1/8 |
4.82 |
3/4 |
19.05 |
9/16 |
14.28 |
15.24 |
17.78 |
27.68 |
7.11 |
35.05 |
-013 |
| AMC 4-4NO |
1/4 |
6.35 |
1/4 |
4.82 |
15/16 |
23.81 |
9/16 |
14.28 |
15.24 |
17.78 |
30.98 |
9.65 |
38.35 |
-113 |
| AMC 6-4NO |
3/8 |
9.52 |
1/4 |
7.11 |
15/16 |
23.81 |
11/16 |
17.46 |
16.76 |
19.30 |
32.51 |
9.65 |
39.87 |
-113 |
| AMC 6-6NO |
3/8 |
9.52 |
3/8 |
7.11 |
1-1/8 |
28.58 |
11/16 |
17.46 |
16.76 |
19.30 |
34.03 |
10.41 |
41.40 |
-116 |
| AMC 6-8NO |
3/8 |
9.52 |
1/2 |
7.11 |
1-5/16 |
33.33 |
11/16 |
17.46 |
16.76 |
19.30 |
39.62 |
13.46 |
46.99 |
-118 |
| AMC 8-8NO |
1/2 |
12.70 |
1/2 |
10.41 |
1-5/16 |
33.33 |
7/8 |
22.22 |
22.86 |
21.84 |
39.62 |
13.46 |
49.78 |
-118 |
